Max Feeding Size: 300mm
Production Capacity: 0-350t/h
Various types of screen surfaces: wire mesh, rod, casting, welding and punching
Applications: smelting, quarry, coal preparation, ore dressing, energy, power, chemical, construction material industries.
The circular vibrating screen is a multi-layer, high – efficiency mahcine, it can divide the material into different sizes. It is widely used in mining, construction, transportation, energy, chemical and other industries for screening and classification.
This vibrating screen has many advantages like long screening line, many screening grades, simple structure,reliable operation, low noise, low power consumption etc.
| Model | Feeding Size (mm) | Capacity (t/h) | Screen Panel (mm) | Screen Area (m²) | Power (kw) | Overall Size (mm) |
| 2YK1548 | 0-200 | 0-160 | 1500*4800 | 7.2 | 11 | 5000*2900*2900 |
| 2YK1860 | 0-200 | 0-200 | 1800*6000 | 10.8 | 15 | 6200*3400*3500 |
| 3YK1860 | 0-300 | 0-200 | 1800*6000 | 10.8 | 22 | 6200*3400*4100 |
| 2YK2460 | 0-200 | 0-300 | 2400*6000 | 14.4 | 22*2 | 6200*4100*3800 |
| 3YK2460 | 0-300 | 0-300 | 2400*6000 | 14.4 | 30*2 | 6200*4100*4400 |
| 2YK3072 | 0-200 | 0-300 | 3000*7200 | 21.6 | 30*2 | 7400*4700*4100 |
| 3YK3072 | 0-300 | 0-300 | 3000*7200 | 21.6 | 30*2 | 7400*4700*4700 |
| 3YK3672 | 0-300 | 0-350 | 3600*7200 | 25.92 | 37*2 | 7400*5400*4700 |
Notice: There is a chance that LDHB may make changes on above-mentioned information. Product pictures and parameters about models, data, performances and specifications on this website are for reference only.
